NSVBAT54SWT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: SC-70, SOT-323
- Description: DIODE ARRAY SCHOTTKY 30V SOT323
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NSVBAT54SWT1G Specifications:
- Mfr Part: NSVBAT54SWT1G
- Mfr: onsemi
- Description: DIODE ARRAY SCHOTTKY 30V SOT323
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
- Item12: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- Part Status: Active
- Diode Configuration: 1 Pair Series Connection
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io) (per Diode): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 800 mV @ 100 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Current - Reverse Leakage @ Vr: 2 µA @ 25 V
- Operating Temperature - Junction: -55°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: SC-70, SOT-323
- NSVBAT54SWT1G onsemi (ON), DIODE ARRAY SCHOTTKY 30V SOT323, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
NSVBAT54SWT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
