NSTR4501NT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23-3 (TO-236)
- Description: MOSFET N-CH 20V 3.2A SOT23-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NSTR4501NT1G Specifications:
- MfrPart.: NSTR4501NT1G
- Mfr: onsemi
- Description: MOSFET N-CH 20V 3.2A SOT23-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 3.2A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): -
- RdsOn(Max)@IdVgs: 80mOhm @ 3.6A, 4.5V
- Vgs(th)(Max)@Id: 1.2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 6 nC @ 4.5 V
- Vgs(Max): -
- InputCapacitance(Ciss)(Max)@Vds: 200 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): -
- OperatingTemperature: -
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23-3 (TO-236)
- NSTR4501NT1G onsemi (ON), MOSFET N-CH 20V 3.2A SOT23-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NSTR4501NT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
