NSTB60BDW1T1 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased Package/Case: 6-TSSOP, SC-88, SOT-363
- Description: TRANS NPN PREBIAS/PNP SOT363
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NSTB60BDW1T1 Specifications:
- MfrPart.: NSTB60BDW1T1
- Mfr: onsemi
- Description: TRANS NPN PREBIAS/PNP SOT363
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- TransistorType: 1 NPN Pre-Biased, 1 PNP
- Current-Collector(Ic)(Max): 150mA
- Voltage-CollectorEmitterBreakdown(Max): 50V
- Resistor-Base(R1): 22kOhms
- Resistor-EmitterBase(R2): 47kOhms
- DCCurrentGain(hFE)(Min)@IcVce: 80 @ 5mA, 10V / 120 @ 5mA, 10V
- VceSaturation(Max)@IbIc: 250mV @ 5mA, 10mA / 500mV @ 5mA, 50mA
- Current-CollectorCutoff(Max): 500nA
- Frequency-Transition: 140MHz
- Power-Max: 250mW
- MountingType: Surface Mount
- Package/Case: 6-TSSOP, SC-88, SOT-363
- NSTB60BDW1T1 onsemi (ON), TRANS NPN PREBIAS/PNP SOT363, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
NSTB60BDW1T1, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
