NSR05301MX4T5G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: 01005 (0402 Metric)
- Description: 01005_TRENCH_SCHOTTKY_30V
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NSR05301MX4T5G Specifications:
- Manufacturer Product Number: NSR05301MX4T5G
- Mfr: onsemi
- Detailed Description: 01005_TRENCH_SCHOTTKY_30V
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io): 500mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 800 mV @ 500 mA
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 11 ns
- Current - Reverse Leakage @ Vr: 100 µA @ 30 V
- Capacitance @ Vr, F: 19pF @ 5V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: 01005 (0402 Metric)
- Operating Temperature - Junction: -55°C ~ 125°C
- NSR05301MX4T5G onsemi (ON), 01005_TRENCH_SCHOTTKY_30V, Discrete Semiconductor Products~Diodes - Rectifiers - Single
