NSM11156DW6T1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased Package/Case: 6-TSSOP, SC-88, SOT-363
- Description: TRANS PNP PREBIAS/PNP 0.23W SC88
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NSM11156DW6T1G Specifications:
- MfrPart.: NSM11156DW6T1G
- Mfr: onsemi
- Description: TRANS PNP PREBIAS/PNP 0.23W SC88
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- TransistorType: 1 PNP Pre-Biased, 1 PNP
- Current-Collector(Ic)(Max): 100mA
- Voltage-CollectorEmitterBreakdown(Max): 50V, 65V
- Resistor-Base(R1): 10kOhms
- Resistor-EmitterBase(R2): 10kOhms
- DCCurrentGain(hFE)(Min)@IcVce: 35 @ 5mA, 10V / 220 @ 2mA, 5V
- VceSaturation(Max)@IbIc: 250mV @ 300µA, 10mA / 650mV @ 5mA, 100mA
- Current-CollectorCutoff(Max): 500nA
- Frequency-Transition: -
- Power-Max: 230mW
- MountingType: Surface Mount
- Package/Case: 6-TSSOP, SC-88, SOT-363
- NSM11156DW6T1G onsemi (ON), TRANS PNP PREBIAS/PNP 0.23W SC88, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
