NSD070ALT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: TO-236-3, SC-59, SOT-23-3
- Description: DIODE ARRAY GP 70V 200MA SOT23-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NSD070ALT1G Specifications:
- Mfr Part: NSD070ALT1G
- Mfr: onsemi
- Description: DIODE ARRAY GP 70V 200MA SOT23-3
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
- Item12: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- Part Status: Active
- Diode Configuration: 1 Pair Common Anode
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 70 V
- Current - Average Rectified (Io) (per Diode): 200mA
- Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Current - Reverse Leakage @ Vr: 5 nA @ 70 V
- Operating Temperature - Junction: -65°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- NSD070ALT1G onsemi (ON), DIODE ARRAY GP 70V 200MA SOT23-3, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
