NSBC143TDXV6T1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased Package/Case: SOT-563, SOT-666
- Description: TRANS PREBIAS 2NPN 50V SOT563
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NSBC143TDXV6T1G Specifications:
- MfrPart.: NSBC143TDXV6T1G
- Mfr: onsemi
- Description: TRANS PREBIAS 2NPN 50V SOT563
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- TransistorType: 2 NPN - Pre-Biased (Dual)
- Current-Collector(Ic)(Max): 100mA
- Voltage-CollectorEmitterBreakdown(Max): 50V
- Resistor-Base(R1): 4.7kOhms
- Resistor-EmitterBase(R2): -
- DCCurrentGain(hFE)(Min)@IcVce: 160 @ 5mA, 10V
- VceSaturation(Max)@IbIc: 250mV @ 1mA, 10mA
- Current-CollectorCutoff(Max): 500nA
- Frequency-Transition: -
- Power-Max: 500mW
- MountingType: Surface Mount
- Package/Case: SOT-563, SOT-666
- NSBC143TDXV6T1G onsemi (ON), TRANS PREBIAS 2NPN 50V SOT563, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
NSBC143TDXV6T1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
