NSBC143EPDP6T5G onsemi TRANS PREBIAS NPN 254MW SOT963
NSBC143EPDP6T5G Images
NSBC143EPDP6T5G Images
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased Package/Case: SOT-963
  • Description: TRANS PREBIAS NPN 254MW SOT963
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
NSBC143EPDP6T5G Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
NSBC143EPDP6T5G Specifications:
  • MfrPart.: NSBC143EPDP6T5G
  • Mfr: onsemi
  • Description: TRANS PREBIAS NPN 254MW SOT963
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
  • Package: Tape & Reel (TR)
  • Series: -
  • PartStatus: Active
  • TransistorType: 1 NPN, 1 PNP - Pre-Biased (Dual)
  • Current-Collector(Ic)(Max): 100mA
  • Voltage-CollectorEmitterBreakdown(Max): 50V
  • Resistor-Base(R1): 4.7kOhms
  • Resistor-EmitterBase(R2): 4.7kOhms
  • DCCurrentGain(hFE)(Min)@IcVce: 15 @ 5mA, 10V
  • VceSaturation(Max)@IbIc: 250mV @ 1mA, 10mA
  • Current-CollectorCutoff(Max): 500nA
  • Frequency-Transition: -
  • Power-Max: 339mW
  • MountingType: Surface Mount
  • Package/Case: SOT-963
  • NSBC143EPDP6T5G onsemi (ON), TRANS PREBIAS NPN 254MW SOT963, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays, Pre-Biased
NSBC143EPDP6T5G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
