NS5A4684SMNTAG Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 10-WFQFN
- Description: IC SWITCH 2 X SPDT 10WFQFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NS5A4684SMNTAG Specifications:
- MfrPart.: NS5A4684SMNTAG
- Mfr: onsemi
- Description: IC SWITCH 2 X SPDT 10WFQFN
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 2
- On-StateResistance(Max): 400mOhm
- Channel-to-ChannelMatching(ΔRon): 100mOhm (Max)
- Voltage-SupplySingle(V+): 1.65V ~ 5.5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 50ns, 30ns
- -3dbBandwidth: 19MHz
- ChargeInjection: 38pC
- ChannelCapacitance(CS(off)CD(off)): 60pF
- Current-Leakage(IS(off))(Max): 100nA
- Crosstalk: -70dB @ 100kHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 10-WFQFN
- NS5A4684SMNTAG onsemi (ON), IC SWITCH 2 X SPDT 10WFQFN, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
NS5A4684SMNTAG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
