NLAS4684MR2 Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
- Description: IC SWITCH DUAL SPDT MICRO10
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NLAS4684MR2 Specifications:
- MfrPart.: NLAS4684MR2
- Mfr: onsemi
- Description: IC SWITCH DUAL SPDT MICRO10
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 2
- On-StateResistance(Max): 800mOhm
- Channel-to-ChannelMatching(ΔRon): 60mOhm
- Voltage-SupplySingle(V+): 1.8V ~ 5.5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 30ns, 30ns
- -3dbBandwidth: 9.5MHz
- ChargeInjection: 15pC
- ChannelCapacitance(CS(off)CD(off)): 102pF, 104pF
- Current-Leakage(IS(off))(Max): 1µA
- Crosstalk: -83dB @ 100kHz
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
- NLAS4684MR2 onsemi (ON), IC SWITCH DUAL SPDT MICRO10, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
NLAS4684MR2, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
