NLAS3699BMN1R2G Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-VFQFN Exposed Pad
- Description: IC SWITCH DUAL DPDT 16QFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NLAS3699BMN1R2G Specifications:
- MfrPart.: NLAS3699BMN1R2G
- Mfr: onsemi
- Description: IC SWITCH DUAL DPDT 16QFN
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: DPDT
- Multiplexer/DemultiplexerCircuit: 2:2
- NumberofCircuits: 2
- On-StateResistance(Max): 550mOhm
- Channel-to-ChannelMatching(ΔRon): 50mOhm
- Voltage-SupplySingle(V+): 1.65V ~ 4.5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 50ns, 50ns
- -3dbBandwidth: 20MHz
- ChargeInjection: 50pC
- ChannelCapacitance(CS(off)CD(off)): 7pF
- Current-Leakage(IS(off))(Max): 500nA
- Crosstalk: -62dB @ 100kHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-VFQFN Exposed Pad
- NLAS3699BMN1R2G onsemi (ON), IC SWITCH DUAL DPDT 16QFN, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
NLAS3699BMN1R2G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
