NL27WZ14DBVT1G Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: SC-74A
- Description: IC INVERT SCHMITT 2CH 2-IN SC74A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NL27WZ14DBVT1G Specifications:
- MfrPart.: NL27WZ14DBVT1G
- Mfr: onsemi
- Description: IC INVERT SCHMITT 2CH 2-IN SC74A
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Tape & Reel (TR)
- Series: 27WZ
- PartStatus: Active
- LogicType: Inverter
- NumberofCircuits: 2
- NumberofInputs: 2
- Features: Schmitt Trigger
- Voltage-Supply: 1.65V ~ 5.5V
- Current-Quiescent(Max): 1 µA
- Current-OutputHighLow: 32mA, 32mA
- LogicLevel-Low: 0.4V ~ 2.3V
- LogicLevel-High: 1V ~ 3.6V
- MaxPropagationDelay@VMaxCL: 4.9ns @ 5V, 50pF
- OperatingTemperature: -55°C ~ 125°C
- MountingType: Surface Mount
- SupplierDevicePackage: SC-74A
- NL27WZ14DBVT1G onsemi (ON), IC INVERT SCHMITT 2CH 2-IN SC74A, Integrated Circuits (ICs)~Logic - Gates and Inverters
