NJL0302DG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-264-5
- Description: TRANS PNP 260V 15A TO264
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NJL0302DG Specifications:
- MfrPart.: NJL0302DG
- Mfr: onsemi
- Description: TRANS PNP 260V 15A TO264
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tube
- Series: -
- PartStatus: Active
- TransistorType: PNP
- Current-Collector(Ic)(Max): 15 A
- Voltage-CollectorEmitterBreakdown(Max): 260 V
- VceSaturation(Max)@IbIc: 1V @ 500mA, 5A
- Current-CollectorCutoff(Max): 10µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 75 @ 3A, 5V
- Power-Max: 180 W
- Frequency-Transition: 30MHz
- OperatingTemperature: -65°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-264-5
- NJL0302DG onsemi (ON), TRANS PNP 260V 15A TO264, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
NJL0302DG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
