NIF9N05CLT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-223 (TO-261)
- Description: MOSFET N-CH 59V 2.6A SOT223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NIF9N05CLT1G Specifications:
- MfrPart.: NIF9N05CLT1G
- Mfr: onsemi
- Description: MOSFET N-CH 59V 2.6A SOT223
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 59 V
- Current-ContinuousDrain(Id)@25°C: 2.6A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 3V, 10V
- RdsOn(Max)@IdVgs: 125mOhm @ 2.6A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 100µA
- GateCharge(Qg)(Max)@Vgs: 7 nC @ 4.5 V
- Vgs(Max): ±15V
- InputCapacitance(Ciss)(Max)@Vds: 250 pF @ 35 V
- FETFeature: -
- PowerDissipation(Max): 1.69W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-223 (TO-261)
- NIF9N05CLT1G onsemi (ON), MOSFET N-CH 59V 2.6A SOT223, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NIF9N05CLT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
