NGTB75N65FL2WAG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-4
- Description: INSULATED GATE BIPOLAR TRANSISTO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB75N65FL2WAG Specifications:
- MfrPart.: NGTB75N65FL2WAG
- Mfr: onsemi
- Description: INSULATED GATE BIPOLAR TRANSISTO
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 200 A
- Current-CollectorPulsed(Icm): 200 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 75A
- Power-Max: 536 W
- SwitchingEnergy: 610µJ (on), 1.2mJ (off)
- InputType: Standard
- GateCharge: 310 nC
- Td(on/off)@25°C: 23ns/157ns
- TestCondition: 400V, 75A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 90 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-4
- NGTB75N65FL2WAG onsemi (ON), INSULATED GATE BIPOLAR TRANSISTO, Discrete Semiconductor Products~Transistors - IGBTs - Single
NGTB75N65FL2WAG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
