NGTB75N60SWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 75A 600V TO-247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB75N60SWG Specifications:
- MfrPart.: NGTB75N60SWG
- Mfr: onsemi
- Description: IGBT 75A 600V TO-247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 100 A
- Current-CollectorPulsed(Icm): 200 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 75A
- Power-Max: 595 W
- SwitchingEnergy: 1.5mJ (on), 1mJ (off)
- InputType: Standard
- GateCharge: 310 nC
- Td(on/off)@25°C: 110ns/270ns
- TestCondition: 400V, 75A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 80 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTB75N60SWG onsemi (ON), IGBT 75A 600V TO-247, Discrete Semiconductor Products~Transistors - IGBTs - Single
