NGTB50N65S1WG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT TRENCH 650V 140A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB50N65S1WG Specifications:
- MfrPart.: NGTB50N65S1WG
- Mfr: onsemi
- Description: IGBT TRENCH 650V 140A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 140 A
- Current-CollectorPulsed(Icm): 140 A
- Vce(on)(Max)@VgeIc: 2.45V @ 15V, 50A
- Power-Max: 300 W
- SwitchingEnergy: 1.25mJ (on), 530µJ (off)
- InputType: Standard
- GateCharge: 128 nC
- Td(on/off)@25°C: 75ns/128ns
- TestCondition: 400V, 50A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 70 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTB50N65S1WG onsemi (ON), IGBT TRENCH 650V 140A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
NGTB50N65S1WG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
