NGTB45N60SWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 45A TO-247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB45N60SWG Specifications:
- MfrPart.: NGTB45N60SWG
- Mfr: onsemi
- Description: IGBT 600V 45A TO-247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Not For New Designs
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 90 A
- Current-CollectorPulsed(Icm): 180 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 45A
- Power-Max: 250 W
- SwitchingEnergy: 550µJ (off)
- InputType: Standard
- GateCharge: 134 nC
- Td(on/off)@25°C: 70ns/144ns
- TestCondition: 400V, 45A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 376 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
