NGTB45N60S2WG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB45N60S2WG Specifications:
- MfrPart.: NGTB45N60S2WG
- Mfr: onsemi
- Description: IGBT
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 90 A
- Current-CollectorPulsed(Icm): 180 A
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 45A
- Power-Max: 300 W
- SwitchingEnergy: 360µJ (off)
- InputType: Standard
- GateCharge: 135 nC
- Td(on/off)@25°C: -/151ns
- TestCondition: 400V, 45A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 498 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTB45N60S2WG onsemi (ON), IGBT, Discrete Semiconductor Products~Transistors - IGBTs - Single
NGTB45N60S2WG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
