NGTB40N65IHRWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT FIELD STOP 650V 80A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB40N65IHRWG Specifications:
- MfrPart.: NGTB40N65IHRWG
- Mfr: onsemi
- Description: IGBT FIELD STOP 650V 80A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 1.7V @ 15V, 40A
- Power-Max: 405 W
- SwitchingEnergy: 420µJ (off)
- InputType: Standard
- GateCharge: 190 nC
- Td(on/off)@25°C: -
- TestCondition: 400V, 40A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTB40N65IHRWG onsemi (ON), IGBT FIELD STOP 650V 80A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
NGTB40N65IHRWG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
