NGTB40N60L2WG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT TRENCH/FS 600V 80A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB40N60L2WG Specifications:
- MfrPart.: NGTB40N60L2WG
- Mfr: onsemi
- Description: IGBT TRENCH/FS 600V 80A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 2.61V @ 15V, 40A
- Power-Max: 417 W
- SwitchingEnergy: 1.17mJ (on), 280µJ (off)
- InputType: Standard
- GateCharge: 228 nC
- Td(on/off)@25°C: 98ns/213ns
- TestCondition: 400V, 40A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 73 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTB40N60L2WG onsemi (ON), IGBT TRENCH/FS 600V 80A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
