NGTB40N120SWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 40A 1200V TO-247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB40N120SWG Specifications:
- MfrPart.: NGTB40N120SWG
- Mfr: onsemi
- Description: IGBT 40A 1200V TO-247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 200 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 40A
- Power-Max: 535 W
- SwitchingEnergy: 3.4mJ (on), 1.1mJ (off)
- InputType: Standard
- GateCharge: 313 nC
- Td(on/off)@25°C: 116ns/286ns
- TestCondition: 600V, 40A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 240 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTB40N120SWG onsemi (ON), IGBT 40A 1200V TO-247, Discrete Semiconductor Products~Transistors - IGBTs - Single
NGTB40N120SWG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
onsemi (ON) Authorized Distributor | NHE is dedicated to providing first-quality, genuine onsemi components.
