NGTB30N65IHL2WG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT TRENCH/FS 650V 60A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB30N65IHL2WG Specifications:
- MfrPart.: NGTB30N65IHL2WG
- Mfr: onsemi
- Description: IGBT TRENCH/FS 650V 60A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 30A
- Power-Max: 300 W
- SwitchingEnergy: 200µJ (off)
- InputType: Standard
- GateCharge: 135 nC
- Td(on/off)@25°C: -/145ns
- TestCondition: 400V, 30A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 430 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTB30N65IHL2WG onsemi (ON), IGBT TRENCH/FS 650V 60A TO247-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
