NGTB30N60L2WG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 30A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB30N60L2WG Specifications:
- MfrPart.: NGTB30N60L2WG
- Mfr: onsemi
- Description: IGBT 600V 30A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube,Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 100 A
- Current-CollectorPulsed(Icm): 60 A
- Vce(on)(Max)@VgeIc: 1.6V @ 15V, 30A
- Power-Max: 225 W
- SwitchingEnergy: 310µJ (on), 1.14mJ (off)
- InputType: Standard
- GateCharge: 166 nC
- Td(on/off)@25°C: 100ns/390ns
- TestCondition: 300V, 30A, 30Ohm, 15V
- ReverseRecoveryTime(trr): 70 ns
- OperatingTemperature: 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTB30N60L2WG onsemi (ON), IGBT 600V 30A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
