NGTB30N135IHR1WG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1350V 30A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB30N135IHR1WG Specifications:
- MfrPart.: NGTB30N135IHR1WG
- Mfr: onsemi
- Description: IGBT 1350V 30A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1350 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 3V @ 15V, 30A
- Power-Max: 394 W
- SwitchingEnergy: 630µA (off)
- InputType: Standard
- GateCharge: 220 nC
- Td(on/off)@25°C: -/200ns
- TestCondition: 600V, 30A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTB30N135IHR1WG onsemi (ON), IGBT 1350V 30A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
NGTB30N135IHR1WG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
