NGTB25N120FL3WG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 100A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB25N120FL3WG Specifications:
- MfrPart.: NGTB25N120FL3WG
- Mfr: onsemi
- Description: IGBT 1200V 100A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 100 A
- Current-CollectorPulsed(Icm): 100 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 25A
- Power-Max: 349 W
- SwitchingEnergy: 1mJ (on), 700µJ (off)
- InputType: Standard
- GateCharge: 136 nC
- Td(on/off)@25°C: 15ns/109ns
- TestCondition: 600V, 25A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 114 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTB25N120FL3WG onsemi (ON), IGBT 1200V 100A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
