NGTB25N120FL2WAG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-4
- Description: IGBT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB25N120FL2WAG Specifications:
- MfrPart.: NGTB25N120FL2WAG
- Mfr: onsemi
- Description: IGBT
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1.2 kV
- Current-Collector(Ic)(Max): 100 A
- Current-CollectorPulsed(Icm): 100 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 25A
- Power-Max: 385 W
- SwitchingEnergy: 990µJ (on), 660µJ (off)
- InputType: Standard
- GateCharge: 181 nC
- Td(on/off)@25°C: 17ns/113ns
- TestCondition: 600V, 50A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 136 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-4
- NGTB25N120FL2WAG onsemi (ON), IGBT, Discrete Semiconductor Products~Transistors - IGBTs - Single
NGTB25N120FL2WAG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
