NGTB20N60L2TF1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3PFM, SC-93-3
- Description: IGBT 600V 20A TO3PF
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB20N60L2TF1G Specifications:
- MfrPart.: NGTB20N60L2TF1G
- Mfr: onsemi
- Description: IGBT 600V 20A TO3PF
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 80 A
- Vce(on)(Max)@VgeIc: 1.65V @ 15V, 20A
- Power-Max: 64 W
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: 84 nC
- Td(on/off)@25°C: 60ns/193ns
- TestCondition: 300V, 20A, 30Ohm, 15V
- ReverseRecoveryTime(trr): 70 ns
- OperatingTemperature: 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3PFM, SC-93-3
- NGTB20N60L2TF1G onsemi (ON), IGBT 600V 20A TO3PF, Discrete Semiconductor Products~Transistors - IGBTs - Single
