NGTB15N120LWG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 30A 156W TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB15N120LWG Specifications:
- MfrPart.: NGTB15N120LWG
- Mfr: onsemi
- Description: IGBT 1200V 30A 156W TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 30 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 15A
- Power-Max: 229 W
- SwitchingEnergy: 2.1mJ (on), 560µJ (off)
- InputType: Standard
- GateCharge: 160 nC
- Td(on/off)@25°C: 72ns/165ns
- TestCondition: 600V, 15A, 15Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- NGTB15N120LWG onsemi (ON), IGBT 1200V 30A 156W TO247-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
NGTB15N120LWG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
onsemi (ON) Authorized Distributor | NHE is dedicated to providing first-quality, genuine onsemi components.
