NGTB10N60R2DT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: INSULATED GATE BIPOLAR TRANSISTO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB10N60R2DT4G Specifications:
- MfrPart.: NGTB10N60R2DT4G
- Mfr: onsemi
- Description: INSULATED GATE BIPOLAR TRANSISTO
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 20 A
- Current-CollectorPulsed(Icm): 40 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 10A
- Power-Max: 72 W
- SwitchingEnergy: 412µJ (on), 140µJ (off)
- InputType: Standard
- GateCharge: 53 nC
- Td(on/off)@25°C: 48ns/120ns
- TestCondition: 300V, 10A, 30Ohm, 15V
- ReverseRecoveryTime(trr): 90 ns
- OperatingTemperature: 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- NGTB10N60R2DT4G onsemi (ON), INSULATED GATE BIPOLAR TRANSISTO, Discrete Semiconductor Products~Transistors - IGBTs - Single
NGTB10N60R2DT4G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
