NGTB03N60R2DT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: IGBT 9A 600V DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGTB03N60R2DT4G Specifications:
- MfrPart.: NGTB03N60R2DT4G
- Mfr: onsemi
- Description: IGBT 9A 600V DPAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 9 A
- Current-CollectorPulsed(Icm): 12 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 3A
- Power-Max: 49 W
- SwitchingEnergy: 50µJ (on), 27µJ (off)
- InputType: Standard
- GateCharge: 17 nC
- Td(on/off)@25°C: 27ns/59ns
- TestCondition: 300V, 3A, 30Ohm, 15V
- ReverseRecoveryTime(trr): 65 ns
- OperatingTemperature: 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- NGTB03N60R2DT4G onsemi (ON), IGBT 9A 600V DPAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
