NGD8205NT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: IGBT 390V 20A 125W DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGD8205NT4G Specifications:
- MfrPart.: NGD8205NT4G
- Mfr: onsemi
- Description: IGBT 390V 20A 125W DPAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 390 V
- Current-Collector(Ic)(Max): 20 A
- Current-CollectorPulsed(Icm): 50 A
- Vce(on)(Max)@VgeIc: 1.9V @ 4.5V, 20A
- Power-Max: 125 W
- SwitchingEnergy: -
- InputType: Logic
- GateCharge: -
- Td(on/off)@25°C: -/5µs
- TestCondition: 300V, 9A, 1kOhm, 5V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- NGD8205NT4G onsemi (ON), IGBT 390V 20A 125W DPAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
NGD8205NT4G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
