NGD18N45CLBT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: INSULATED GATE BIPOLAR TRANSISTO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NGD18N45CLBT4G Specifications:
- MfrPart.: NGD18N45CLBT4G
- Mfr: onsemi
- Description: INSULATED GATE BIPOLAR TRANSISTO
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 500 V
- Current-Collector(Ic)(Max): 18 A
- Current-CollectorPulsed(Icm): 50 A
- Vce(on)(Max)@VgeIc: 2.3V @ 4.5V, 7A
- Power-Max: 115 W
- SwitchingEnergy: -
- InputType: Logic
- GateCharge: -
- Td(on/off)@25°C: 420ns/2.9µs
- TestCondition: 300V, 1kOhm, 5V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- NGD18N45CLBT4G onsemi (ON), INSULATED GATE BIPOLAR TRANSISTO, Discrete Semiconductor Products~Transistors - IGBTs - Single
