NDUL09N150CG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-3PF-3
- Description: MOSFET N-CH 1500V 9A TO3PF-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NDUL09N150CG Specifications:
- MfrPart.: NDUL09N150CG
- Mfr: onsemi
- Description: MOSFET N-CH 1500V 9A TO3PF-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 1500 V
- Current-ContinuousDrain(Id)@25°C: 9A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 3Ohm @ 3A, 10V
- Vgs(th)(Max)@Id: 4V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 114 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 2025 pF @ 30 V
- FETFeature: -
- PowerDissipation(Max): 3W (Ta), 78W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-3PF-3
- NDUL09N150CG onsemi (ON), MOSFET N-CH 1500V 9A TO3PF-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
