NDTL01N60ZT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-223 (TO-261)
- Description: MOSFET N-CH 600V 250MA SOT223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NDTL01N60ZT1G Specifications:
- MfrPart.: NDTL01N60ZT1G
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: MOSFET N-CH 600V 250MA SOT223
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 250mA (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): -
- RdsOn(Max)@IdVgs: 15Ohm @ 400mA, 10V
- Vgs(th)(Max)@Id: 4.5V @ 50µA
- GateCharge(Qg)(Max)@Vgs: 4.9 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 92 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 2W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-223 (TO-261)
- NDTL01N60ZT1G onsemi (ON), MOSFET N-CH 600V 250MA SOT223, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
