NDP603AL Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220-3
- Description: MOSFET N-CH 30V 25A TO220-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NDP603AL Specifications:
- MfrPart.: NDP603AL
- Mfr: onsemi
- Description: MOSFET N-CH 30V 25A TO220-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 25A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 22mOhm @ 25A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 40 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1100 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 50W (Tc)
- OperatingTemperature: -65°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220-3
- NDP603AL onsemi (ON), MOSFET N-CH 30V 25A TO220-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NDP603AL, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
