NDF10N60ZH Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: -
- Description: MOSFET N-CH 600V 10A TO220FP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NDF10N60ZH Specifications:
- MfrPart.: NDF10N60ZH
- Mfr: onsemi
- Description: MOSFET N-CH 600V 10A TO220FP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 10A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 750mOhm @ 5A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 100µA
- GateCharge(Qg)(Max)@Vgs: 68 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 1645 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 39W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: -
- NDF10N60ZH onsemi (ON), MOSFET N-CH 600V 10A TO220FP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
