NDDL01N60ZT4G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 600V 800MA DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NDDL01N60ZT4G Specifications:
- MfrPart.: NDDL01N60ZT4G
- Mfr: onsemi
- Description: MOSFET N-CH 600V 800MA DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 800mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 15Ohm @ 400mA, 10V
- Vgs(th)(Max)@Id: 4.5V @ 50µA
- GateCharge(Qg)(Max)@Vgs: 4.9 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 92 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 26W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- NDDL01N60ZT4G onsemi (ON), MOSFET N-CH 600V 800MA DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NDDL01N60ZT4G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
