NDD03N80Z-1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I-Pak
- Description: MOSFET N-CH 800V 2.9A IPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NDD03N80Z-1G Specifications:
- MfrPart.: NDD03N80Z-1G
- Mfr: onsemi
- Description: MOSFET N-CH 800V 2.9A IPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 2.9A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 4.5Ohm @ 1.2A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 50µA
- GateCharge(Qg)(Max)@Vgs: 17 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 440 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 96W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I-Pak
- NDD03N80Z-1G onsemi (ON), MOSFET N-CH 800V 2.9A IPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
