NCV7724DQBR2G Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: 24-LSSOP (0.154, 3.90mm Width) Exposed Pad
- Description: 8 CHANNEL HALF-BRIDGE DRIVER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NCV7724DQBR2G Specifications:
- MfrPart.: NCV7724DQBR2G
- Mfr: onsemi
- Description: 8 CHANNEL HALF-BRIDGE DRIVER
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q100
- PartStatus: Active
- OutputConfiguration: Half Bridge (8)
- Applications: DC Motors, General Purpose
- Interface: Logic, PWM, SPI, Serial
- LoadType: Inductive, Capacitive
- Technology: NMOS
- RdsOn(Typ): 800mOhm LS, 800mOhm HS
- Current-Output/Channel: 1.1A
- Current-PeakOutput: 1.1A
- Voltage-Supply: 3.15V ~ 5.25V
- Voltage-Load: 3.15V ~ 5.25V
- OperatingTemperature: -40°C ~ 150°C (TJ)
- Features: Charge Pump
- FaultProtection: Over Current, Over Temperature, UVLO
- MountingType: Surface Mount
- Package/Case: 24-LSSOP (0.154, 3.90mm Width) Exposed Pad
- NCV7724DQBR2G onsemi (ON), 8 CHANNEL HALF-BRIDGE DRIVER, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
