NCP1055ST100T3G Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers Package/Case: TO-261-4, TO-261AA
- Description: IC OFFLINE SWITCH FLYBACK SOT223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NCP1055ST100T3G Specifications:
- MfrPart.: NCP1055ST100T3G
- Mfr: onsemi
- Description: IC OFFLINE SWITCH FLYBACK SOT223
- Product Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- OutputIsolation: Isolated
- InternalSwitch(s): Yes
- Voltage-Breakdown: 700V
- Topology: Flyback
- Voltage-StartUp: 8.5 V
- Voltage-Supply(Vcc/Vdd): 7.5V ~ 10V
- DutyCycle: 77%
- Frequency-Switching: 100kHz
- Power(Watts): 40 W
- FaultProtection: Current Limiting, Open Loop, Over Load, Over Temperature
- ControlFeatures: -
- OperatingTemperature: -40°C ~ 150°C (TJ)
- Package/Case: TO-261-4, TO-261AA
- NCP1055ST100T3G onsemi (ON), IC OFFLINE SWITCH FLYBACK SOT223, Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
NCP1055ST100T3G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
