NCD5701CDR2G Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: IC GATE DRVR HI/LOW SIDE 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NCD5701CDR2G Specifications:
- MfrPart.: NCD5701CDR2G
- Mfr: onsemi
- Description: IC GATE DRVR HI/LOW SIDE 8SOIC
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- DrivenConfiguration: High-Side or Low-Side
- ChannelType: Synchronous
- NumberofDrivers: 1
- GateType: IGBT
- Voltage-Supply: 20V
- LogicVoltage-VILVIH: -
- Current-PeakOutput(SourceSink): 7.8A, 6.8A
- InputType: -
- HighSideVoltage-Max(Bootstrap): -
- Rise/FallTime(Typ): 18ns, 19ns
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- NCD5701CDR2G onsemi (ON), IC GATE DRVR HI/LOW SIDE 8SOIC, Integrated Circuits (ICs)~PMIC - Gate Drivers
NCD5701CDR2G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
