NC7ST00P5X Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: SC-70-5
- Description: IC GATE NAND 1CH 2-INP SC70-5
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NC7ST00P5X Specifications:
- MfrPart.: NC7ST00P5X
- Mfr: onsemi
- Description: IC GATE NAND 1CH 2-INP SC70-5
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: 7ST
- PartStatus: Active
- LogicType: NAND Gate
- NumberofCircuits: 1
- NumberofInputs: 2
- Features: -
- Voltage-Supply: 4.5V ~ 5.5V
- Current-Quiescent(Max): 1 µA
- Current-OutputHighLow: 2mA, 2mA
- LogicLevel-Low: 0.8V
- LogicLevel-High: 2V
- MaxPropagationDelay@VMaxCL: 26ns @ 5.5V, 50pF
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- SupplierDevicePackage: SC-70-5
- NC7ST00P5X onsemi (ON), IC GATE NAND 1CH 2-INP SC70-5, Integrated Circuits (ICs)~Logic - Gates and Inverters
