MUR1560H Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: TO-220-2
- Description: REC 4A 600V ULTFST H-FREE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MUR1560H Specifications:
- Manufacturer Product Number: MUR1560H
- Mfr: onsemi
- Detailed Description: REC 4A 600V ULTFST H-FREE
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tray
- Series: SWITCHMODE™
- Part Status: Obsolete
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 600 V
- Current - Average Rectified (Io): 15A
- Voltage - Forward (Vf) (Max) @ If: 1.5 V @ 15 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 60 ns
- Current - Reverse Leakage @ Vr: 10 µA @ 600 V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: TO-220-2
- Operating Temperature - Junction: -65°C ~ 175°C
- MUR1560H onsemi (ON), REC 4A 600V ULTFST H-FREE, Discrete Semiconductor Products~Diodes - Rectifiers - Single
MUR1560H, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
