MSR1560G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: TO-220-2
- Description: DIODE GEN PURP 600V 15A TO220-2
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MSR1560G Specifications:
- Manufacturer Product Number: MSR1560G
- Mfr: onsemi
- Detailed Description: DIODE GEN PURP 600V 15A TO220-2
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tube
- Series: SWITCHMODE™
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 600 V
- Current - Average Rectified (Io): 15A
- Voltage - Forward (Vf) (Max) @ If: 1.8 V @ 15 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 45 ns
- Current - Reverse Leakage @ Vr: 15 µA @ 600 V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: TO-220-2
- Operating Temperature - Junction: -65°C ~ 150°C
- MSR1560G onsemi (ON), DIODE GEN PURP 600V 15A TO220-2, Discrete Semiconductor Products~Diodes - Rectifiers - Single
