MPSA14 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-226-3, TO-92-3 Long Body
- Description: TRANS NPN DARL 30V 0.5A TO-92
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MPSA14 Specifications:
- MfrPart.: MPSA14
- Mfr: onsemi
- Description: TRANS NPN DARL 30V 0.5A TO-92
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN - Darlington
- Current-Collector(Ic)(Max): 500 mA
- Voltage-CollectorEmitterBreakdown(Max): 30 V
- VceSaturation(Max)@IbIc: 1.5V @ 100µA, 100mA
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 20000 @ 100mA, 5V
- Power-Max: 625 mW
- Frequency-Transition: 125MHz
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-226-3, TO-92-3 Long Body
- MPSA14 onsemi (ON), TRANS NPN DARL 30V 0.5A TO-92, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
MPSA14, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
