MPS6560G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-226-3, TO-92-3 Long Body
- Description: TRANS NPN 25V 0.5A TO92
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MPS6560G Specifications:
- MfrPart.: MPS6560G
- Mfr: onsemi
- Description: TRANS NPN 25V 0.5A TO92
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 500 mA
- Voltage-CollectorEmitterBreakdown(Max): 25 V
- VceSaturation(Max)@IbIc: 500mV @ 50mA, 500mA
- Current-CollectorCutoff(Max): 100nA
- DCCurrentGain(hFE)(Min)@IcVce: 50 @ 500mA, 1V
- Power-Max: 625 mW
- Frequency-Transition: 60MHz
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-226-3, TO-92-3 Long Body
- MPS6560G onsemi (ON), TRANS NPN 25V 0.5A TO92, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
