MOC8101S Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 6-SMD, Gull Wing
- Description: OPTOISOLATOR 5.3KV TRANS 6-SMD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MOC8101S Specifications:
- MfrPart.: MOC8101S
- Mfr: onsemi
- Description: OPTOISOLATOR 5.3KV TRANS 6-SMD
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Obsolete
- NumberofChannels: 1
- Voltage-Isolation: 5300Vrms
- CurrentTransferRatio(Min): 50% @ 10mA
- CurrentTransferRatio(Max): 80% @ 10mA
- TurnOn/TurnOffTime(Typ): 2µs, 3µs
- Rise/FallTime(Typ): 1µs, 2µs
- InputType: DC
- OutputType: Transistor
- Voltage-Output(Max): 30V
- Current-Output/Channel: 50mA
- Voltage-Forward(Vf)(Typ): 1.15V
- Current-DCForward(If)(Max): 100 mA
- VceSaturation(Max): 400mV
- OperatingTemperature: -55°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 6-SMD, Gull Wing
- MOC8101S onsemi (ON), OPTOISOLATOR 5.3KV TRANS 6-SMD, Isolators~Optoisolators - Transistor, Photovoltaic Output
MOC8101S, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
