MOC223R2M Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: OPTOISO 2.5KV DARL W/BASE 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MOC223R2M Specifications:
- MfrPart.: MOC223R2M
- Mfr: onsemi
- Description: OPTOISO 2.5KV DARL W/BASE 8SOIC
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 2500Vrms
- CurrentTransferRatio(Min): 500% @ 1mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 10µs, 125µs
- Rise/FallTime(Typ): 8µs, 110µs
- InputType: DC
- OutputType: Darlington with Base
- Voltage-Output(Max): 30V
- Current-Output/Channel: 150mA
- Voltage-Forward(Vf)(Typ): 1.08V
- Current-DCForward(If)(Max): 60 mA
- VceSaturation(Max): 1V
- OperatingTemperature: -40°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- MOC223R2M onsemi (ON), OPTOISO 2.5KV DARL W/BASE 8SOIC, Isolators~Optoisolators - Transistor, Photovoltaic Output
MOC223R2M, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
