MOC211M Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: OPTOISO 2.5KV TRANS W/BASE 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MOC211M Specifications:
- MfrPart.: MOC211M
- Mfr: onsemi
- Description: OPTOISO 2.5KV TRANS W/BASE 8SOIC
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 2500Vrms
- CurrentTransferRatio(Min): 20% @ 10mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 7.5µs, 5.7µs
- Rise/FallTime(Typ): 3.2µs, 4.7µs
- InputType: DC
- OutputType: Transistor with Base
- Voltage-Output(Max): 30V
- Current-Output/Channel: 150mA
- Voltage-Forward(Vf)(Typ): 1.15V
- Current-DCForward(If)(Max): 60 mA
- VceSaturation(Max): 400mV
- OperatingTemperature: -40°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- MOC211M onsemi (ON), OPTOISO 2.5KV TRANS W/BASE 8SOIC, Isolators~Optoisolators - Transistor, Photovoltaic Output
MOC211M, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
